Specification
| Electrical Specification | |
|---|---|
| Impedance | 50 Ohm |
| Frequency Range | Up to 3GHz |
| Dielectric Withstand Voltage | 1500 Veff |
| Insulation Resistance | 5000 M-Ohm |
| Mechanical Specification | |
| Design Standard | IEC 61169-8 |
| RoHS3 Compliant | Yes |
| Centre Contact Termination | Solder |
| Outer Contact Termination | Clamp |
| Mating Cycles | 250 |
| Contact Retention | 10N min |
| Cable Retention | 100N min |
| Weight | 16.g |
| Mating Force | 13.6N max |
| Un-Coupling Force | 13.6N max |
| Environmental Specification | |
| Operating Temperature | -55 to +155 Deg C |
| IP Rating ( Mated ) | IP64 |
| Materials | |
| Centre Contact | Brass |
| Outer Contact | Brass |
| Insulator | PTFE |
| Bayonet Cap | Zinc |
| Centre Contact Plating | Gold |
| Outer Contact Plating | Nickel |
| Pack Size | 1 |
